507 Mechanical Movements: Mechanisms and Devices

This compendium of ingenious mechanisms employs simple drawings to explain 507 of the small components that constitute complex machinery. Left-hand pages feature illustrations and facing pages offer brief descriptions of use and operation. Ranging from simple to complex the mechanisms include cranks pulleys drills wheels and screws.
