A reliable logic bist with scalable approach

We propose a novel scalable approach to reduce the PD during at-speed test of sequential circuits with scan-based LBIST using the launch-on-capture scheme. This is achieved by reducing the activity factor of the CUT by proper modification of the test vectors generated by the LBIST of sequential ICs. The generation of significant power droop (PD) during at-speed test performed by Logic Built-In Self Test (LBIST) is a serious concern for modern ICs.
