Advanced Interconnect and Packaging

<p>Unlike transistors the continuous downscaling of feature size in CMOS technology leads to a dramatic rise in interconnect resistivity and concomitant performance degradation. At nanoscale technology nodes interconnect delay and reliability become the major bottlenecks faced by modern integrated circuits. To resolve these interconnect problems various emerging technologies including airgap nanocarbon optical and through-silicon via (TSV) have been proposed and investigated. For example by virtue of TSV technology dies can be stacked to increase the integration density. More importantly 3D integration and packaging also offer the most promising platform to implement More-than-Moore technologies providing heterogeneous materials and technologies on a single chip. </p><p>The Advanced Interconnect and Packaging Special Issue seeks to showcase research papers on new developments in advanced interconnect and packaging i.e. on the design modeling fabrication and reliability assessment of emerging interconnect and packaging technologies. Additionally there are two interesting papers on carbon nanotube interconnects and interconnect reliability issues.</p>
