Analysis and Estimation of Jitter Sub-Components

Maintaining quality of signal transmission is a major challenge with the increasing speed of data transmission in Nano-scale VLSI technology. The decreasing voltage margins at the same time makes it even stringent to maintain Power Integrity (PI) and Signal Integrity (SI) in high speed systems. Jitter is an important phenomenon of signal integrity. This Book contains fundamentals of signal integrity jitter definition and their classification summary of previous research work on jitter a detailed explanation and implementation of different types of jitter estimation techniques using MATLAB. The strength and limitations of tail-fit improved tail fit and spectrum approach for jitter segregation are discussed. Further mathematical models of different jitter sources are implemented. At the end a new technique for ISI estimation from total jitter using clock pattern is introduced. Authors: Vijender K. Sharma Rajkumar Nagpal Dr. Jai Narayan Tripathi Dr. Sujay Deb Rakesh Malik.
