Business Practice Report

This report shows the calculation memory for the pre-dimensioning of the hydraulic structures (intake adduction conduction and discharge) of a Small Hydroelectric Power Plant (SHP) located in the department of Antioquia in the sub-basin of the river or water source under study which is of the run-of-the-river type.Hydroelectric Power Plant (SHP) located in the department of Antioquia in the sub-basin of the river or water source under study which is of the run-of-the-river type. For this purpose topographic hydrological and technical aspects were taken into account. The pre-dimensioning was carried out using fluid mechanics and hydraulics techniquessupported by primary and secondary information (topographic and hydrological). Hydrological studies were started by estimating average minimum maximum and environmental flow rates. Then the company''s design area defined the location of the catchment and discharge works in order to make the hydraulic utilization layouts and select the most technically optimal in terms of generation capacity and percentage of total losses. Then the calculation for the pre-dimensioning of the hydraulic structures of the selected alternative was completed.
