Characterization of Uav Performance and Development of a Formation Flight Controller for Multiple Small Uavs

The Air Force Institute of Technologys (AFIT) Advanced Navigation Technology (ANT) Center has recently delved into the research topic of small Unmanned Aerial Vehicles (UAV). One area of particular interest is using multiple small UAVs cooperatively to improve mission efficiency as well as perform missions that couldnt be performed using vehicles independently. However many of these missions require that the UAVs operate in close proximity with each other. This research lays the foundation required to use the ANT Centers UAVs for multi-vehicle missions (e.g. cooperatively) by accomplishing two major goals. First it develops test procedures that can be used to characterize the tracking performance of a small UAV being controlled by a waypoint guided autopilot. This defines the size of the safety zones that must be maintained around each vehicle to ensure no collisions assuming no as yet unspecified collision avoidance algorithm is being implemented. Secondly a formation flight algorithm is developed that can be used to guide UAVs relative to each other using a waypoint guided autopilot. This is done by dynamically changing the waypoints. Such an approach gives a wrap-around method of cooperatively controlling UAVs that can only be guided waypoint-to-waypoint. For both components of this research tests were conducted using a hardware-in-the-loop (HITL) simulation before validating through flight testing. This report along with legacy documentation and procedures furthers the UAV test bed at AFIT and establishes methods for simulating visualizing and flight testing multiple UAVs during formation/cooperative flight.
