Circuits and Electronics

<p>The book provides instructions on building circuits on breadboards connecting the Analog Discovery wires to the circuit under test and making electrical measurements. Various measurement techniques are described and used in this book including: impedance measurements complex power measurements frequency response measurements power spectrum measurements current versus voltage characteristic measurements of diodes bipolar junction transistors and Mosfets. The book includes end-of-chapter problems for additional exercises geared towards hands-on learning experimentation comparisons between measured results and those obtained from theoretical calculations.</p>
