Decimation Lowpass Filters for SIGMA-DELTA Modulators - A Comparative Study

Masters Thesis from the year 1998 in the subject Electrotechnology grade: 10 (A) University of Rhode Island (--) language: English abstract: The purpose of this thesis is to compare several filter topologies used for the decimation of sigma-delta modulated digital signals. The goal is to present optimized filter architectures with regard to an efficient VLSI implementation. A fifth-order 1-bit sigma-delta modulator using local feedback techniques will be considered as the front-end A/D converter. The subsequent digital filter reduces the sampling rate by a factor of 32. The decimation filter must guarantee a narrow transition band between 0.5 and 0.55 and stopband attenuation of 100dB. Chapter 1 provides a brief introduction into the principles of digital signal processing. The considerations are focused on FIR filters due to the requirements for acoustic applications. Chapter 2 illustrates the proposed overall structure and the design flow. The objective of chapter 3 is to present the principles of oversampling data converters using sigma-delta techniques. The 5V fifth-order SigmaDelta-modulator with 90dB dynamic range (SNR+THD) will be presented which has been fabricated in 1.2$um CMOS technology. For the sake of simplicity and robustness a 1-bit quantizer will be used. Chapter 4 deals with typical hardware realizations of digital filters. Apart from the ``brute force implementation of the multirate filter with identical filters running in parallel also the LUT-based approach for small filter orders will be presented. Due to the advantages of compact implementation the bit-serial approach and the bit-serial multiplier are investigated in detail. In chapter 5 the straightforward one-stage multirate FIR filter will be introduced. To satisfy the specifications a 4096 tap lowpass FIR filter will be designed. The influence of coefficient quantization is investigated and furthermore the ``block scaling method to represent small values is presente
