Design and Implementation of a Novel Multilevel Inverter

A novel multilevel dc–ac inverter is proposed. The proposed multilevel inverter generates seven-level ac output voltage with the appropriate gate signals’ design. Also the low-pass filter is used to reduce the total harmonic distortion of the sinusoidal output voltage. The switching losses and the voltage stress of power devices can be reduced in the proposed multilevel inverter. The operating principles of the proposed inverter and the voltage balancing method of input capacitors are discussed. The multilevel inverter is controlled with sinusoidal pulse-width modulation (SPWM).
