Design/Development of Spacecraft and Module Crew Compartments

This slide presentation reviews the design and development of crew compartments for spacecraft and for modules. The Crew Compartment or Crew Station is defined as the spacecraft interior and all other areas the crewman interfaces inside the cabin or may potentially interface.It uses examples from all of the human rated spacecraft. It includes information about the process significant drivers for the design habitability definitions of models mockups prototypes and trainers including pictures of each stage in the development from Apollo pictures of the space shuttle trainers and International Space Station trainers. It further reviews the size and shape of the Space Shuttle orbiter crew compartment and the Apollo command module and the lunar module. It also has a chart which reviews the International Space Station (ISS) internal volume by stage. The placement and use of windows is also discussed. Interestingly according to the table presented the number 1 rated piece of equipment for recreation was viewing windows. The design of crew positions and restraints crew translation aids and hardware restraints is shown with views of the restraints and handholds used from the Apollo program through the ISS.
