Development of a Multiple Beam Combiner Using Stimulated Raman Scattering in Multimode Fiber

<p>Beam combination was demonstrated by splitting the beam from a diode pumped Q-switched Nd:YAG laser and pumping a multiple input single output fiber squid. Beam cleanup of the resulting output beam using stimulated Raman scattering was then demonstrated in both 100 ?m fiber (Stokes M2 = 1.86) and 200 ?m fiber (Stokes M2 = 1.40). The performance of the 200 ?m fiber was compared to that of the 100 ?m fiber. Energy conversion efficiency into the Stokes beam was measured as a function of input energy and found to be limited by the attenuation characteristics of the fiber. When input energy was increased the conversion efficiency of pump energy to Stokes energy decreased. In the 100 ?m fiber the pump-to-Stokes conversion efficiency decreased from a high of 44% to a low of 16% as input pump energy increased. In the 200 ?m fiber the pump-to-Stokes conversion efficiency decreased from a high of 19% to a low of 12% as input pump energy increased. For a given input pump energy the 200 ?m fiber was more efficient than the 100 ?m fiber. Beam quality was measured via the M2 fit parameter as a function of input energy and was found to slightly degrade in both fibers as input energy increased. In addition beam quality was measured as a function of 100 ?m fiber length and determined to degrade slightly (M2 lt; 2.5) at fiber lengths less than 400 m. Additional fiber length beyond 400 m did not improve beam quality and reduced output energy although the Stokes threshold was reduced.</p><p>This work has been selected by scholars as being culturally important and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact and remains as true to the original work as possible. Therefore you will see the original copyright references library stamps (as most of these works have been housed in our most important libraries around the world) and other notations in the work.</p><p>This work is in the public domain in the United States of America and possibly other nations. Within the United States you may freely copy and distribute this work as no entity (individual or corporate) has a copyright on the body of the work.</p><p>As a reproduction of a historical artifact this work may contain missing or blurred pages poor pictures errant marks etc. Scholars believe and we concur that this work is important enough to be preserved reproduced and made generally available to the public. We appreciate your support of the preservation process and thank you for being an important part of keeping this knowledge alive and relevant.</p><br>
