Electroencephalogram and Analysis

Electroencephalography is an electrophysiological monitoring method to record electrical activity of the brain. The Source of EEG is is WITHIN the cerebral cortex by pyramidal cells. The 10-20 System of Electrode Placement is a method used to describe the location of scalp electrodes. Each electrode placement site has a letter to identify the lobe or area of the brain. A stable electrical connection between electrode and scalp is key to recording clean EEG signals. EEG waveforms with different frequency are displayed. Different types of montages are discussed. Standard EEG Test is carried out with analog or digital EEG equipment. Ambulatory EEG test (Continuous monitoring) is also available. Invasive test  is done for evaluation of eligible patients  for epileptic surgery. Different types of EEG electrodes are given. DYNOGRAPH analog EEG m/c is discussed with Pre amplifier Power amplifier and Pen motor. Computerized EEG Machine is discussed about the software filtering of 50Hz.  Photic Stimulator evoked potential polysomogram are  discussed.  Analog to Digital Conversion and Micro Controller are mentioned with color figures. Maintenance and Repair of EEG m/c is discussed elaborately. PMMC instrument is explained with figures. Chart paper movement is controlled by motor and electronics circuit. Neuro-feedback or EEG biofeedback is a very specific protocol is explained with equipments. Rheoencephalograph Radio telemetry. EEG only gives lively records of Epilepsy.
