Electronic Circuits

Diode circuit: load line concept clipping circuits comparators sampling gate rectifiers capacitive filters additional diode circuit. Transistor: the junction transistor transistor as an amplifier transistor construction the CE configuration the CB configuration the CE cut-off and saturation region common emitter current gain the common collector configuration analytical expression for transistor characteristics the photo-transistor. Transistor at low frequency: graphical analysis of the CE model two-port model and hybrid model transistor hybrid model the h-parameter analysis of transistor amplifier circuit using h parameter the emitter follower miller’s theorem and its duality cascading transistor amplifiers simplified CE and CC configuration.
