Electronic Instrumentation & Measurements

<p>Book contain Performance characteristics of Instruments: Static characteristics Accuracy Precision Resolution Sensitivity static and dynamic calibration Errors in Measurement and their statistical analysis dynamic characteristics-speed of Response fidelity Lag and dynamic error. DC ammeters DC voltmeters-multirange range extension/solid state and differential voltmeters AC voltmeters -multirange range extension. Thermocouple type RF ammeter ohm meters series type shunt type multimeter for voltage current and resistance measurements. Oscilloscopes: Standard specifications of CROCRT features derivation of deflection sensitivity vertical and horizontal amplifiers horizontal and vertical deflection systems sweep trigger pulse delay line sync selector circuits probes for CRO - active passive and attenuator type triggered sweep CRO and Delayed sweep dual trace/beam CRO Measurement of amplitude frequency and phase (Lissajous method).Principles of sampling oscilloscope storage oscilloscope and digital storage oscilloscope Digital frequency counters time & Period measurements. Signal generators-fixed and variable AF oscillators function generators pulse random noise sweep and arbitrary waveform generators their standards specifications and principles of working (Block diagram approach).Wave analyzers Harmonic distortion analyzers Spectrum analyzers and Logic analyzers. </p>
