Electronic Nanodevices

<p>The start of high-volume production of field-effect transistors with a feature size below 100 nm at the end of the 20th century signaled the transition from microelectronics to nanoelectronics. Since then downscaling in the semiconductor industry has continued until the recent development of sub-10 nm technologies.</p><p>The new phenomena and issues as well as the technological challenges of the fabrication and manipulation at the nanoscale have spurred an intense theoretical and experimental research activity. New device structures operating principles materials and measurement techniques have emerged and new approaches to electronic transport and device modeling have become necessary. Examples are the introduction of vertical MOSFETs in addition to the planar ones to enable the multi-gate approach as well as the development of new tunneling high-electron mobility and single-electron devices. The search for new materials such as nanowires nanotubes and 2D materials for the transistor channel dielectrics and interconnects has been part of the process.</p><p>New electronic devices often consisting of nanoscale heterojunctions have been developed for light emission transmission and detection in optoelectronic and photonic systems as well for new chemical biological and environmental sensors.</p><p>This Special Issue focuses on the design fabrication modeling and demonstration of nanodevices for electronic optoelectronic and sensing applications.</p>
