Fabrication and Cold-Flow Testing of Subscale Space-Based Laser Geometry

<p>The objectives of this research were to build a facility that could simulate the expected fluid flow properties in the conceptual Space Based Laser Integrated Flight Experiment (SBL IFX) gas dynamic laser using cold-flow and to investigate the performance of the model. A 1/5-scale model of one quadrant of the SBL IFX cylindrical gas dynamic laser was fabricated and mated to a blow-down/vacuum combination wind tunnel. The primary components of the test apparatus consisted of a nozzle array optical cavity supersonic diffuser centerbody and transition. The throat height of a single nozzle was 1 mm and the expansion ratio was two. The transition structure was designed to attach the subscale model to the wind tunnel facility vacuum line and was not part of the SBL IFX design. Using rapid data acquisition and schlieren photography the fluid velocities in the diffuser where determined to became subsonic after a transient time interval of 0.2 seconds from wind tunnel startup for a 30 second long test. During this transient time interval a well-defined attached oblique shock wave was observed off the leading edge of the centerbody within the optical cavity of the diffuser and the fluid in the optical cavity reached an observed maximum Mach number of 2.7. The brevity of the supersonic flow within the optical cavity was due to the minimum area of the transition structure being too small to swallow a normal shock that propagates down the length of the test section during a transient time period at wind tunnel startup.</p><p>This work has been selected by scholars as being culturally important and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact and remains as true to the original work as possible. Therefore you will see the original copyright references library stamps (as most of these works have been housed in our most important libraries around the world) and other notations in the work.</p><p>This work is in the public domain in the United States of America and possibly other nations. Within the United States you may freely copy and distribute this work as no entity (individual or corporate) has a copyright on the body of the work.</p><p>As a reproduction of a historical artifact this work may contain missing or blurred pages poor pictures errant marks etc. Scholars believe and we concur that this work is important enough to be preserved reproduced and made generally available to the public. We appreciate your support of the preservation process and thank you for being an important part of keeping this knowledge alive and relevant.</p>
