Face Gear Drive with Helical Involute Pinion: Geometry Generation by a Shaper and a Worm Avoidance of Singularities and Stress Analysis

A new type of face-gear drive with intersected axes of rotation formed by a helical involute pinion and conjugated face-gear has been investigated. Generation of face-gears by a shaper free of undercutting and pointing has been investigated. A new method of grinding or cutting of face-gears by a worm of special shape has been developed. A computerized design procedure has been developed to avoid undercutting and pointing by a shaper or by a generating worm. Also a method to determine the limitations of the helix angle magnitude has been developed. The method provides a localization of the bearing contact to reduce the shift of bearing contact caused by misalignment. The analytical method provides a simulation of the meshing and contact of misaligned gear drives. An automatic mesh generation method has been developed and used to conduct a 3D contact stress analysis of several teeth. The theory developed is illustrated with several examples.
