FE Analysis and Optimization of CNC Turning Center Structure

In machine tool design to optimize the design finally analysis becomes powerful tool for designer and thus it is required to analyze the various structures i.e. head slant bed column slides over arm etc. of machine tool before arriving at final design decision. Again it is very difficult to analyze the structure analytically and moreover the accurate results for stress deflection etc. are the limitations of this method. In machine tool Structure like beds bases columns box-type housing over arms carriages and tables are containing major weight. In machine tools 70-80 percentage of the total weight of the machine is due to the structure. The present paper deals with analyze and optimize the head stock and bed of CNC turning Center Q- Plus. Static structural analysis of head stock and bed of CNC turning center is carried out. Based on result of Stress and displacement obtained in static structural analysis optimization of existing structure has been done.
