Generalized Modelling And Simulation Of Three Phase Induction Motor

This book presents a step by step Simulink implementation of an induction machine using dq0 axis transformations of the stator and rotor variables in the arbitrary reference frame. At first we have studied few journals and then drafted the equations needed for this project implementation. Then using Matlab/Simulink we have transformed the equations into block. After this a generalized model of a three phase induction motor is developed and implemented. Electromagnetic torque Speed Direct and quadrature axis stator currents & Voltages characteristics are found out by varying loads and compared with theoretical results. The proposed system has been developed and simulated by using Matlab/Simulink.
