Graphical Debugging of QVT Relations using Transformation Nets

Diploma Thesis from the year 2009 in the subject Computer Science - Commercial Information Technology grade: 1 Vienna University of Technology (Institute of Software Technology and Interactive Systems) language: English abstract: Model transformations (MT) play a key role in the Model Driven Engineering (MDE) paradigm leading to the standardization of the Query/View/Transformation (QVT) model transformation language by the Object Management Group (OMG). Until now however this language did not attract the same interest as the Unified Modeling Language (UML) because of the lack of adequate debugging facilities which are necessary regarding the following three problem areas: First declarative languages like QVT Relations (QVT-R) hides the operational semantics of transformations. Only the information provided by the interpreter as well as the tendered inputs and returned outputs are available for tracking the progress of transformations. Furthermore the ordering of transformation application is hidden by the MT engines providing only a black-boxes view to the users. This can lead to the problem of impedance mismatches between design and runtime. These characteristics of QVT-R are assets for developing but are handicaps for debugging. Second QVT-R code is specified on higher abstraction level than its execution and state-of-the-art debugging. This deteriorates the ability to deduce causes from produced results. Third the information content responsible for operating MTs is spread over several artifacts including the input model a resulting target model and the QVT-R code. As a consequence the reasons for a particular outcome are hard to be derived from the involved artifacts. This severely harms the ease of debugging.Therefore this master thesis tackles the mentioned problems by visualizing QVT-R as Transformations Nets using the MT framework Transformations On Petri Nets In Color (TROPIC) based on Colored Petri Nets (CPN). This can be seen as expli
