High Performance CMOS Multiplier Barrel Shifter and Modeling of NBTI

The objective of this book is to explore the design space of two specific data path elements (viz multipliers and barrel shifters) of different bit width at architectural-level at logic design level and at transistor size level to select proper architecture logic design style and physical device sizes; keeping in a view their effects on performance (circuit delay) average power consumption and core area. The multipliers and barrel shifters are the fundamental data path elements required in high performance ‘Standard Digital Signal Processors’ and ‘ASIC Digital Signal Processors’ used for digital signal processing (DSP). Different multiplier and barrel shifter architectures show trade-offs between propagation delay average power consumption and transistor counts. In deep sub-micron technologies the simple gate-level analyses are inadequate to validate particular data path architectures. In this work we considered the effects of wiring parasitics and MOS parasitics in the assessment of architecture. The selected word widths for different multiplier and barrel shifter architectures are 4-bit 8-bit 12-bit and 16-bit; which dominate in DSP applications.
