INSTRUMENTATION SIMULATION LAB

The proposed text book is a lab practical handbook used as a reference book for UG students. It covers ten experiments on Instrumentation simulations. The software used in this are: MATLAB and LabVIEW. The list of experiments are as follows:1. Verification of Network Theorems i) Superposition theorem. ii) Thevenin’s theorem. iii) Maximum power transfer theorem.2. Transient responses of series RLC RL RC circuits with Sine and Stepinputs.3. Series and Parallel resonance.4. Bode plot Root-locus plot and Nyquist plot.5. Transfer function analysis of i) Time response of step input ii) Frequency response for sinusoidal input.6. Design of Lag Lead and Lag-Lead compensators.7. Design and Simulation of Pressure Monitoring System using LabVIEW8. Simulation of Tank Level Control System using LabVIEW9. Analysis of an ECG Waveform using LabVIEW10. Design of Temperature Monitoring System using LabVIEW
