Linear Integrated Circuit Question Set

The book contains: current mirror and current sources Current sources as active loads Voltage sources Voltage References BJT Differential amplifier with active loads Basic information about op-amps – Ideal Operational Amplifier – General operational amplifier stages and internal circuit diagrams of IC 741 DC and AC performance characteristics slew rate Open and closed loop configurations – JFET Operational Amplifiers – LF155 and TL082. Sign Changer Scale Changer Phase Shift Circuits Voltage Follower V-to-I and I-to-V converters adder subtractor Instrumentation amplifier Integrator Differentiator Logarithmic amplifier Antilogarithmic amplifier Comparators Schmitt trigger Precision rectifier peak detector clipper and clamper Low-pass high-pass and band-pass Butterworth filters.
