Low Power Techniques Based Schmitt Trigger Circuit

In this book we have revealed a novel type of Schmitt trigger circuit which illustrates some noteworthy result. We have realized the Schmitt trigger circuit by the use of FinFET. The Schmitt trigger circuit is very noteworthy in producing a clean pulse from the input signal comprising of noise. There are various applications of Schmitt trigger circuit in VLSI system such as in scheming the oscillator circuit analog to digital converter function generator signal conditioning and numerous applications. Thus it becomes imperative to boost its performance by plummeting the leakages and power consumption of the Schmitt trigger circuit.
