Measurement Systems

The book contains: Block Schematics of Measuring Systems: Performance characteristics Static characteristics Accuracy Precision Resolution Types of Errors Dynamic Characteristics Repeatability Reproducibility Fidelity Lag; Measuring Instruments: DC Voltmeters D''Arsonval Movement DC Current Meters AC Voltmeters and Current Meters Ohmmeters Multi-meters Meter Protection Extension of Range True RMS Responding Voltmeters Specifications of Instruments. Signal Analyzers: AF HF Wave Analyzers Harmonic Distortion Heterodyne wave Analyzers Spectrum Analyzers Capacitance-Voltage Meters Signal Generators: AF RF Signal Generators Sweep Frequency Generators Pulse and Square wave Generators Function Generators Arbitrary waveform Generator. Oscilloscopes: CRT Block Schematic of CRO Time Base Circuits Lissajous Figures CRO Probes High Frequency CRO Considerations Delay lines Applications: Measurement of Time Period and Frequency. Special Purpose Oscilloscopes: Dual Trace Dual Beam CROs Sampling Oscilloscopes Storage Oscilloscopes Digital Storage CROs.
