Modelica. Modeling and Simulation Based on Dymola Program

Bachelor Thesis from the year 2013 in the subject Electrotechnology grade: A Islamic University of Gaza language: English abstract: Modelica is an object-oriented declarative multi-domain language for component-oriented modeling of complex systems e.g. systems containing mechanical electrical electronic hydraulic thermal control electric power or process-oriented subcomponents. Modelica language is a textual description to define all parts of a model and to structure model components in libraries called packages. Basically all Modelica language elements are mapped to differential algebraic and discrete equations. Using Modelica in design process for complex systems is very efficient and provide several benefits results. In Modelica we can model and simulate all types of components such as electrical mechanical hydraulic etc. Furthermore Modelica Association provide standard library which contains a lot of different components.
