Modeling and Analysis of Automotive Wheel Rim

The rim of a wheel is the outer circular design of the metal on which the inside edge of the tire is mounted on vehicles such as automobiles. Wheel rim is the part of automotive where it heavily undergoes both static loads as well as fatigue loads as wheel rim travels different road profile. It develops heavy stresses in rim so we have to find the critical stress point and we have to find for how many number cycle that the wheel rim is going to fail. In this project The 3D model of an automotive wheel rim is created with proper dimension using modeling software and the created model is analyzed on an analysis software. The stress and strain displacement of an object is analyzed with different materials and the result of each material is compared.
