Modeling Fracture in Z-Pinned Composite Co-Cured Laminates Using Smeared Properties and Cohesive Elements in DYNA3D

<p>The purpose of the present research was three-fold: 1) gain a more sophisticated understanding of the response of co-cured composite joints with and without through-thickness reinforcement (TTR) 2) compare the behavior of specimens reinforced with various sizes and densities of reinforcement and 3) use experimental data to verify the existing DYNA3D smeared property model.Double cantilever beam end-notch flexure and T-section specimens reinforced with 0.011 diameter z-pins at 2% and 4% volume densities were tested to determine the mode I mode II and mixed mode (I and II) behavior. Results were added to preliminary research in which tests were conducted on previously mentioned specimen geometries reinforced with 0.022 diameter z-pins at similar densities.Experiments were modeled in DYNA3D using shell and cohesive elements. The energy release rate G determined through a curve fit developed from beam theory was smeared across the region of reinforcement treating it as a separate material.The research validated Z-pinning as an effective means of improving the fracture toughness of polymer matrix laminated composites in mode I and mixed mode loading conditions and determined that the existing model works well in simulating the behavior in mode I tests.</p><p>This work has been selected by scholars as being culturally important and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact and remains as true to the original work as possible. Therefore you will see the original copyright references library stamps (as most of these works have been housed in our most important libraries around the world) and other notations in the work.</p><p>This work is in the public domain in the United States of America and possibly other nations. Within the United States you may freely copy and distribute this work as no entity (individual or corporate) has a copyright on the body of the work.</p><p>As a reproduction of a historical artifact this work may contain missing or blurred pages poor pictures errant marks etc. Scholars believe and we concur that this work is important enough to be preserved reproduced and made generally available to the public. We appreciate your support of the preservation process and thank you for being an important part of keeping this knowledge alive and relevant.</p>
