Next Generation MRAM Development

Only recently has the possibility of a universal memory a fast random access memory that retains its state during complete power-down turned into a realizable opportunity. Such a memory can eliminate static power improve system reliability in the face of power interruption and eliminate the need for a separate FLASH memory module reducing system component count. One candidate in the race for a universal memory is magnetoresistive random access memory (MRAM). In the development of MRAM design challenges related to isolating memory elements obtaining a compatible operating point with CMOS technology and sensing data reliably have emerged. Therefore there still exists a barrier to achieving the cost and performance characteristics of traditional volatile solid state memories---SRAM and DRAM. In this work a 4kb MRAM array is designed to evaluate the feasibility of a promising new form of MRAM based on the phenomenon of spin torque transfer switching. The design of the test site and measurement setup is discussed showing how to explore a multidimensional parameter space of operating conditions to obtain a viable design point for the next generation of MRAM technology.
