Parallel Prefix Adder Architecture

Two-operand binary addition is the most widely used arithmetic operation in modern data path designs. To improve the efficiency of this operation it is desirable to use an adder with good performance and area trade-off characteristics. This work presents an efficient carry- look-ahead adder architecture based on the parallel-prefix computation graph. In this book we define the notion of triple-carry-operator which computes the generateand propagate signals for a merged block which combines three adjacent blocks. We use conjunction with the classic approach of the carry-operator to compute the generate and propagate signals for a merged block combining two adjacent blocks. The timing-driven nature of the proposed design reduces the depth of the adder. In addition we use a ripple-carry type of structure in the non-timing critical portion of the parallel-prefix computationnetwork.
