Power Quality Management in Integrated System Using UPQC

The L-C series-filter and passive double-resonant circuits (PDR) are then discussed along with the key circuit components of the design the series inductor (LL) circuit the PDR passive low-pass and the passive double resonant circuit design for applying the induct filtering. After all the proof of results in the high voltage delivery validation using UPQC in MATLAB/Simulink IHUPQC has been demonstrated 10kV distribution now is supported. With these effects it being effective in regulating voltage and current and dynamic power generation the simulation results show the performance of dynamic grid voltage & current regulation and dynamic load-harmonic regulation
