Practical Pattern Making

Practical Pattern Making by Paul N. Hasluck was first published in 1905. Written in simple concise language and full of helpful diagrams this timeless volume will be of considerable utility to anyone with an interest in designing and creating foundry patterns.A foundry pattern is a counterpart of a casting and is used to form the mould into which the molten metal is poured. Patten-making is thus a very important part of foundry work and the pattern-maker must be a craftsman of experience and of more than ordinary intelligence.The competent pattern maker has a knowledge of practical plane and solid geometry and of mechanical drawing; he is constantly required to lay upon an uneven angular surface lines which the ordinary draughtsman can get much more easily on smooth surface of paperContents include: Foundry Patterns and Foundry Practice Jointing-up Patterns Finishing Patterns Circular Patterns Making Core-boxes Coring Holes in Castings Patterns and Moulds for Iron Columns Steam-engine Cylinder Patterns and Core-boxes Worm Wheel Pattern Lathe-bed Patterns Headstock and Poppet Patterns Slide-rest Patterns etc. Many vintage books such as this are increasingly scarce and expensive. We are republishing this volume now in an affordable modern high-quality edition complete with the original text and artwork.
