Simulation of Some Power Electronics Case Studies Using Matlab Simpowersystem Blockset

Matlab SimPowerSystems is a modern design tool that allows scientists and engineers to rapidly and easily build models that simulate power systems. Not only can you draw the circuit topology rapidly but your analysis of the circuit can include interactions with mechanical thermal control and other disciplines. The paper covers some case studies that provide detailed realistic examples of how to use SimPowerSystems in power system analysis. The following types of studies are covered on the paper:1. Thyristor-Based Static Var Compensator: Study the steady-state and dynamic performance of a static var compensator (SVC) on a transmission system.2. Transient Stability of a Power System with SVC and PSS: Study of the application of static var compensator (SVC) and power system stabilizers (PSS) to improve transient stability and power oscillation damping of the system. 3. GTO-Based STATCOM: Study the steady-state and dynamic performance of a static synchronous compensator (STATCOM) on a transmission system. 4. Control of load flow using UPFC: Study the steady-state and dynamic performance of a unified power flow controller (UPFC).5. Variable-frequency Induction Motor Drive: Study of a PWM inverter is used as a variable-voltage variable-frequency source to drive an induction motor in variable-speed operation.6. Chopper-Fed DC Motor Drive: Study of a DC motor drive with armature voltage controlled by a GTO thyristor chopper.7. VSC-Based HVDC Link: Modeling of a forced-commutated voltage-sourced converter high-voltage direct current (VSC-HVDC) transmission link.
