Structures of Angled Aerated-Liquid Jets in Mach 1.94 Supersonic Crossflow

<p>The structures of aerated-liquid jets injected into a supersonic crossflow have been studied experimentally. Aerated-liquid injectors with diameters of 0.020 0.040 and 0.060 were flush mounted on the bottom plate of a supersonic wind tunnel to provide normal and angled injection. Freestream Mach number and temperature were held constant at 1.94 and 500 -F respectively. Water at room temperature was used as the liquid injectant and nitrogen gas used as the aerating gas. Wide ranges of test conditions for injection angle injector orifice diameter (d0) jet-to-air momentum flux ratios (q0) and gas-to-liquid ratios (GLR) were studied. Injection angles were varied from 45- downstream to 90- (normal to freestream). Jet-to-air momentum flux was varied from 1% to 15% of the freestream and gas-to-liquid ratios from 0% (pure-liquid injection) to 10%. Shadowgraph and laser sheet illumination techniques were used for spray visualization while a phase Doppler particle analyzer (PDPA) was utilized to quantitatively measure droplet and spray plume properties. The data from all three methods were used to develop correlations for the droplet and spray plume properties for aerated-liquid jets using a linear fit of the base-10 logarithm coefficients.</p><p>This work has been selected by scholars as being culturally important and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact and remains as true to the original work as possible. Therefore you will see the original copyright references library stamps (as most of these works have been housed in our most important libraries around the world) and other notations in the work.</p><p>This work is in the public domain in the United States of America and possibly other nations. Within the United States you may freely copy and distribute this work as no entity (individual or corporate) has a copyright on the body of the work.</p><p>As a reproduction of a historical artifact this work may contain missing or blurred pages poor pictures errant marks etc. Scholars believe and we concur that this work is important enough to be preserved reproduced and made generally available to the public. We appreciate your support of the preservation process and thank you for being an important part of keeping this knowledge alive and relevant.</p>
