The Impact of Integration of TCSC on Power Grid Stability

Stability of power grid is an important topic due to the high penetration of wind energy. This needs the development of advanced techniques for the analysis and the study of the system control of power grids. For this reason this book investigates the efficiency of synchronous machine using different order models to describe the dynamic behavior of wind energy and to deal with the influence of the integration of an energy source at the base of synchronous machine on the security and stability of the electricity grid. Five different synchronous machine models are presented. Furhemore this book proposes to inegrate the TCSC between buses 2 and 5 and shows its influence on power grid. The recommended network is the IEEE 14 bus. A comparative efficiency performance is obtained by processing active and reactive power showing the evolution of the dynamic angle and voltage. The simulations of other machines model.
