Three Phase PWM Rectifiers-Design Simulation Study

Solid state power frequency changers are used for various purposes.The usual practice to get variable frequency power source is to use rectifier-inverter combination.Unfortunately the conventional diode/thyristor bridge rectifiers at the input side cause several problems such as:low input power factorconsiderable harmonic distortion of ac currents and harmonic pollution on grid. The PWM rectifier is a preferred choice for providing ac to d.c conversiondue to its capability of input p.f regulationline harmonic current mitigationd.c voltage control and bidirectional power flow.In this thesis workthe theory behind a three phase PWM rectifier has been studied.a controller is designed to regulate the output voltage and input power factor.The entire system with its controller is modeled and simulated in MATLAB-simulink to verify the effectiveness of the proposed control strategyto set the controller gains exactly to ascertain certain ratings of few hardware implementation.In this thesis workreal time simulation of a three phase PWM rectifier system with the proposed control strategy has been done using FPGA.
