Ultrathin Two-Dimensional Semiconductors for Novel Electronic Applications

<p>Offering perspective on both the scientific and engineering aspects of 2D semiconductors <b><i>Ultrathin Two-Dimensional Semiconductors for Novel Electronic Applications</i></b> discusses how to successfully engineer 2D materials for practical applications. It also covers several novel topics regarding 2D semiconductors which have not yet been discussed in any other publications. </p><p>Features:</p><ul> <p> </p> <li>Provides comprehensive information and data about wafer-scale deposition of 2D semiconductors ranging from scientific discussions up to the planning of experiments and reliability testing of the fabricated samples </li> <p> </p> <li>Precisely discusses wafer-scale ALD and CVD of 2D semiconductors and investigates various aspects of deposition techniques </li> <p> </p> <li>Covers the new group of 2D materials synthesized from surface oxide of liquid metals and also explains the device fabrication and post-treatment of these 2D nanostructures</li> <p> </p> <li>Addresses a wide range of scientific and practical applications of 2D semiconductors and electronic and optoelectronic devices based on these nanostructures </li> <p> </p> <li>Offers novel coverage of 2D heterostructures and heterointerfaces and provides practical information about fabrication and application of these heterostructures</li> <p> </p> <li>Introduces the latest advancement in fabrication of novel memristors artificial synapses and sensorimotor devices based on 2D semiconductors</li> </ul><p>This work offers practical information valuable for engineering applications that will appeal to researchers academics and scientists working with and interested in developing an array of semiconductor electronic devices.</p>
