Wide Area Measurement & Control - Techniques & Assessment

Market and environment constraints force power systems to be operated closer to their limits and utilize the existing assets much better. To achieve this while keeping high security is a challenging task. Various technical solutions fulfilling this mission have recently been proposed. This work report and describe how a wide area protection system can be designed and implemented. Such a system can be used to mitigate voltage collapse loss of synchronism power oscillations etc. the protection system is based on a number of protection terminals connected via a system wide data communication network and synchronized by GPS technology. The system is very flexible and comprises a large number of optional protection functions of various complexity and capability.
